ARBOR SHAFT – Tool steel machined to 3/4 inch bearing diameter. 5/8 inch diameter for blade arbor
BLADE FLANGES – Steel 2 inch outside diameter
BLADE – Greenline Agate Eater sintered diamond blade
SAFE START SYSTEM – Contactor control system reduces the risk of accidental startup
AUTOMATIC CUT-OFF SWITCH – Adjustable for length of cut
POWERFEED – Approximate workpiece infeed rates 11-1/4 inches per hour, 3/16 inches per minute
SPLIT NUT DRIVE – Engages carriage with powerfeed screw. Released by a flip of the handle for quick carriage return
PRECISION CARRIAGE – Carriage rides on precision-ground hardened steel rails retained by adjustable precision roller bearings for smooth travel
CROSSFEED WAYS – 1/2 inch precision ground steel
SAW BOX – Welded 16 gauge steel. Inside dimensions 18 inches wide x 9 inches deep x 25 inches long. Overall height with the hood closed – 16-1/4 inches
VISE – Steel vise jaws
– Maximum workable jaw opening 4-1/2 x 7 inches
– Lateral travel of vise assembly 2-1/2 inches
V-BELT – Connects motor to the saw blade
MOTOR – 110 volt 1/2 H.P. with thermal protection and start capacitor
